The Explo X2 Wave Flame Head is a fluid driven flame effect with moving-head technology. This compact flame effect can produce flames up to 9m high which can rotate in 1 direction for 210°! With a built-in 10 liter fluid reservoir and a built-in pump system there is no need for any additional pressure vessels and is it very simple to set-up the effect that provides creative people endless possibilities.
Size: 55.8 cm x 33.5 cm x 35.2 cm Weight: 27 kg Voltage: 230 V Power: 350 W Control: DMX-512 DMX channels: 6 Output: max 10 m  Consumables: ISOPAR, Bioethanol or Isopropylalcohol

Explo X2 Wave Flame, incl. outdoor nozzle

The Explo X2 Wave Flame Head is a fluid driven flame effect with moving-head technology. This compact flame effect can produce flames up to 9m high which can rotate in 1 direction for 210°! With a built-in 10 liter fluid reservoir and a built-in pump system there is no need for any additional pressure vessels and is it very simple to set-up the effect that provides creative people endless possibilities.




The Magix FX Flameblazer is a new state of the art liquid flame system. This high quality flame head is extremely fast and responsive. It is very reliable because of its high quality pump, dual ignition and its fully integrated, key-activated enable circuit. It can be activated and secured by the new remote arm controller. Safety for everyone on stage and user confidence for the FX operator! A revolution in special FX, next level safety!
Size: 41 cm x 30 cm x 27.5 cm Weight: 18.6 kg Voltage: 220-250 VAC Power: 395 W Control: DMX-512 DMX channels: 2 Output: S nozzle up to 6 m / M nozzle up to 8 m / L nozzle up to 10 m max Consumables: Isopropanol / Isopar

Magic FX Flameblazer 5-way, incl. nozzle "L"

The Magix FX Flameblazer is a new state of the art liquid flame system. This high quality flame head is extremely fast and responsive. It is very reliable because of its high quality pump, dual ignition and its fully integrated, key-activated enable circuit. It can be activated and secured by the new remote arm controller. Safety for everyone on stage and user confidence for the FX operator! A revolution in special FX, next level safety!

Magic FX Flameblazer, incl. nozzle "L"

uFlamer® II is the second generation liquid flame thrower to generate bigger and higher flames than it’s prodecessor uFlamer. And it is the first liquid flamer equipped with flame monitoring functions. With dual built-in high pressure pump, it can generate a powerful flame throw upto 12m with better combustion rate. Aluminum housing struture, durable metal tube structure, multi safety configurations etc to meet the high demanding professional market. Specifications:  Dimension: 460 x 330 x 330mm  Weight: 25kg  Input and Power: 100-240VAC, 50/60 Hz, 500W  Housing Material: Aluminum  Effect Direction: Vertical  Max. Flame Height (No Wind): Nozzle H: 10-12m  Fuels: ISOPAR G, H, L, M; ISOPROPANOL  Fuel Tank Capacity: 8L  Fuel Consumption Rate:Nozzle M: 60ml/s  Interface: NEUTRIK POWERCON TRUE1 IN/OUT;Waterproof 3-pin and 5-pin XLR IN/OUT  Control: DMX, 9-60V Pyro Signal  E-stop: Yes  ARM Indicator Light: Yes  Liquid Level Sensor: Yes  Ignition: High Voltage Electron Ignition * 2  Valve: Dual  Pump: Dual  Built-in Battery Design: Yes, 18650 battery  Use in Rain: Yes
Description Features and advantages  Bigger and higher flame upto 12m  Aluminum housing struture, premium quality design  Powerful dual pump ensure higher combustion rate, less fuel residue  The first liquid flamer with flame monitoring function  Multi safety configurations: cascadable power cut-off E-stop connector, ARM indicator light, safety switch etc.  Dual valve, dual igniter  8L Built-in fuel tank  Durable metal tube structure  Built-in 18650 battery design

uFlamer II, incl. nozzle “PM”

uFlamer ®Max AVM is a customized version of uFlamer® Max, with a firing duration up to 3 seconds, designed for professionals who require longer firing durations.
uFlamer ®Max is the first standalone liquid flamer with flames upto to 20m. Built-in pumping system and fuel tank makes it the only plug and play big liquid flame units available on market. Equipped with auxillary igniter and triple high voltage igniters ensure successful ignition. Specifications:  Dimension: 690 x 475 x 415mm  Weight: 80kg  Input and Power: 200-240VAC, 50/60 Hz, 2.5KW  Housing Material: 304 Stainless steel  Effect Direction: Vertical  Max. Flame Height (No Wind): Nozzle XXH: 20m  Fuels: ISOPAR G, H, L, M; ISOPROPANOL  Fuel Tank Capacity: 30L  Fuel Consumption Rate: Appr. 1L/s  Interface: NEUTRIK POWERCON TRUE1 IN/OUT;Waterproof 3-pin and 5-pin XLR IN/OUT  Control: DMX, 9-60V Pyro Signal  E-stop: Yes  ARM Indicator Light: Yes  Liquid Level Sensor: Yes  Ignition: High Voltage Electron Ignition * 3  Firing Duration: 0.2-0.5s  Use in Rain: Yes
Features and advantages  The first standalone liquid flamer with flames upto to 20m  Built-in pump and fuel tank, plug and play system  Equipped with external fuel input quick coupler  Compact size  Triple high voltage igniters  Flame monitoring function  Multi safety configurations: cascadable power cut-off E-stop connector, ARM indicator light, safety switch etc.  Durable metal tube structure

uFlamer Max AVM, incl. nozzle “XXH”

uFlamer Volcano is high end liquid flamer system with five nozzles, each nozzle can firing individually or simultaneously. Volcano with 90 preset firing sequences, 25L built-in fuel tank and pumping system, multi safety design and reliable valve component allowing operators to create spectacular firing effects much easier. It is an ideal choice for fireworks displays, outdoor concert, opening ceremony, sports, scenic area etc.
<ul>
<li>5-heads plug and play liquid flamer with effects up to 10</li>
<li>Independent control of each head</li>
<li>25L built-in stainless steel fuel tank,support automati crefueling station</li>
<li>Real-time fuel level display</li>
<li>Integrated valve block design, premium and independent jet valve</li>
<li>Customized waterproof igniter and structure design, can be used in rain</li>
<li>DMX control, compatible with 9-60V pyro signal</li>
<li>Safety switch, intelligent electronic control alarming system</li>
</ul>
Size: 63 cm x 45 cm x 40 cm Weight: 48 kg Voltage: 200-240 VAC Power: 2000 W Control: DMX-512 or pyro signal (9-60V)  DMX channels: 6 Output: max 10 m Consumables: Isopropanol / Isopar

uFlamer Volcano, incl. nozzles “M”

uFlamer Volcano is high end liquid flamer system with five nozzles, each nozzle can firing individually or simultaneously. Volcano with 90 preset firing sequences, 25L built-in fuel tank and pumping system, multi safety design and reliable valve component allowing operators to create spectacular firing effects much easier. It is an ideal choice for fireworks displays, outdoor concert, opening ceremony, sports, scenic area etc.
Features and advantages:

5-heads plug and play liquid flamer with effects up to 10m
Independent control of each head
25L built-in stainless steel fuel tank,support automati crefueling station
Real-time fuel level display
Integrated valve block design, premium and independent jet valve
Customized waterproof igniter and structure design, can be used in rain
DMX control, compatible with 9-60V pyro signal
Safety switch, intelligent electronic control alarming system





Liquid Flames SFX Standalone
